DC Power Meter RS485

DJSF1352-RN

Standard Lead Time:
Sample: 2 days
Bulk: 1 month

  • Hall Sensor
  • Current Diverter
  • DC1000V
  • Modbus-RTU

Feedback

What Do Our Customers Say?

  • My first contact with ACREL was through Mrs. Feeling Chang. He was extremely friendly, approachable and very helpful. It will be the beginning of a long partnership between Bikoelectronics and Acrel.

    Vanessa 

    Portugal

  • “ For over 4 years working with Acrel, they have continuously demonstrated excellent technical ability while ensuring superior customer service. Their collaborative approach and real time flexibility in adapting to changing conditions has contributed to the success of many project goals. "

    Arnold 

    Philippines

  • Cloud Platform for Power IoT is a synchronous integrated solution from energy meter installation to web interactive interface that can see the benefits of features with the first click mouse. Very convenient and fast. I will be with this product for a long time.

    Tuan 

    Vietnam

Highlight

What’s the Function of Acrel DJSF1352 series DC Power Meter RS485?

Voltage & Current

  • input voltage can be up to DC1000V
  • Splitter 0-75mV
  • Hall Sensor 0-20mA,4-20mA,0-5V,0-10V
  • Accuracy: 0.5 or 1 class

Communication

  • RS485
  • Modbus-RTU
  • Infrared

Function

  • DC Voltage, Current, Power Measurement;
  • Forward and Reverse Electric Energy Measurement
  • 2DI/2DO: 2 Dry Contact Input; 2 Relay Output

Auxiliary Power Supply

  • AC 85-265V
  • DC 85-265V
  • DC 24V
  • DC 48V

Application

What’s the Application of Acrel DJSF1352 series DC Power Meter RS485?

EV Charger
Cell Tower
Solar

Specification

What’s the Specification of Acrel DJSF1352 series DC Power Meter RS485?

Dual Independent DC Circuits Monitoring

● For Twin EV Charger&Battery

● Voltage Input: DC 0~1000V

● Current Input (by Shunt): 0~75mV

● Current Input (by Hall Sensor): 0~5V, 0~10V, 0~20mA, 4~20mA

 Built-in Bipolar Power Source

● Power Supply for Hall Effect CT

● Range: DC -12V ~ DC +12V

 Optional Dual RS485 Communication

● Protocol: MODBUS-RTU

● 1 RS485 (standard)

 DO/DI Function

● 2 DO (2A/30V DC; 2A/250V AC)

● 2 DI (dry contact)

Parameter

What’s the Parameter of Acrel DJSF1352 series DC Power Meter RS485?

Technical parameters Indicators
Input Nominal value Voltage input range Current input
DC 0-1000V Shunt:0-75mV;
See the physical wiring diagram Hall sensor:0-20mA、4-20mA、0-5V,0-10V, etc
Overload 1.2 times rated (continuous); 2 times rated/1 second;
Power consumption Voltage: ≤0.2VA, current ≤0.1VA
Accuracy class Class 1
Function Display 8-bit segment LCD screen (LCD)
Communication Interface RS485, infrared
Communication protocol Modbus-RTU, DL/T 645-2007
Switch Switch output 2 Relay outputs, 2A/30VDC or 2A/250VA
Switch input 2 dry contact inputs
Pulse output A second pulse output, an energy pulse output
See the SYS->PLUS display in the meter menu setting
For example, The meter displays 100, which is 100imp/kWh
Power Supply Voltage range AC/DC 85-265V or DC24V(±10%) or DC48V(±10%)
Power consumption ≤ 3W
Power frequency withstands voltage Power supply // Voltage input // Current input // Relay output and switch input // Communication interface / / Pulse output 3kV/1minPower supply // Relay output // Voltage input // Current input 3kV/1minPulse output // Communication interface // Switch input 2kV/1min
Insulation resistance ≥ 40M Ω
Average barrier-free working hours ≥50000h

Installation

How to Install theAcrel DJSF1352 series DC Power Meter RS485?


Wiring with Shunt Wiring with Hall Sensor
